| Parameters | MUX | DEMUX |
| 插损 Insettion Loss(dB) | ≤5.5 | ≤5.5 |
| ITU channel | CH21-60 |
| 波长 Operating Wavelength (nm) | 1560.61-1529.55 |
| Min Channel Spacing(GHz) | 100 |
| 带宽 Passband (@-0.5dB bandwidth)(nm) | ±0.11 |
| 隔离度 Insettion | Adjacent Channel | > 30 |
| Non-Adjacent Channel | > 40 |
| 通带波动 Passband Ripple (dB) | ≤0.30 |
| 偏振损耗 Polarization Dependent Loss (dB) | ≤0.30 |
| 偏振色散 Polarization Mode Dispersion (ps) | < 0.10 |
| 回损 Return Loss (dB) | > 45 |
| 方向性 Directivity (dB) | > 50 |
| 功率 Maximum Optical Power (mw) | 500 |
| 工作温度 Operating Temperature (℃) | -5 ~ +75 |
| 储存温度 Storage Temperature (℃) | -40 ~ +85 |
| 光纤类型 Fiber Type | Corning SMF-28 |
| 封装尺寸Package Dimension (mm) | ABS：120*80*18 Or 140*114*18 |
